E190CG
Jusha display for endoscopic surgery only uses LCD panel with accurate color reproduction,good sense of hierarchy,smooth dynamic display and wide visual range.It satisfy the rapid changing needs for medical display.In minimally invasive surgery (MIS),it can clearly observe the position of surgery.The white frame,the compliance with electromagnetic compatibility and many video input and output interfaces make the product fully meet the requirements of various endoscopy or operating room and ICU display.
1.Characteristics
With the 36 bit technology, JUSHA display for endoscopic surgery only can represent over 68.7 billion colors and accurately reproduce the colors of human issues in MIS, so that the surgeons can make more accurate judgments.
2.Good sense of hierarchy
The most advanced medical LCD panel used by JUSHA display for endoscopic surgery only has good sense of hierarchy, high brightness and high contrast, thus it can represent the hierarchy of any issue in the surgery and provide clear clinical surgery images.
3.Smooth dynamic image
The response time of the gray scale of JUSHA display for endoscopic surgery only is less than 14ms, thus it can smoothly present the surgery images from standard definition to high definition and clearly display bleeding and other meticulous operations in the surgery without smearing and shaking.
4.Compliance with the requirements of cleansing and anti-interference in the operating room
The white dust-free design used by JUSHA display for endoscopic surgery only meets the cleansing requirements of operating equipment in the operating room. The closed metal design can effectively prevent dust and liquid pollution during the surgery. The body with metal shell and the built-in shield circuit can effectively prevent the interference of electric operating equipment such as high frequency electric knife to the monitor, thus it can ensure the stability of surgical display.
5.Various types of interfaces
JUSHA display for endoscopic surgery only can be compatible with various analog signals and digital signals as well as the image pick-up systems of hard lens manufactures and soft lens manufactures in the world. lt fully meets the needs of various brands and equipment.
Model | E190CG |
Type | IPS |
Backlight | LED |
Diagonal size | 19" (479.96 mm) |
Display area | 374.784 × 299.827 mm |
Resolution | 1280 × 1024 |
Aspect ratio | 5:4 |
Pixel Pitch | 0.2928 × 0.2928 mm |
Color Depth | 8-bit |
LUT Depth | 12-bit |
Viewing angles | 178° |
Maximum brightness (typical) | 250 cd/m² |
Maximum calibrated brightness | 200 cd/m² |
Default brightness | 150 cd/m² |
Minimum brightness | 100 cd/m² |
Presets | GAMMA1.8, GAMMA2.0, GAMMA2.2, GAMMA2.4, GAMMA2.6, DICOM |
Contrast ratio | 1000:1 |
Response time (Ton+Toff)/2 | 14 ms |
Features | PIP |
Video input | DVI × 1, VGA × 1, CVBS × 1, S-VIDEO × 1, YPbPr × 1, RGBS × 1 |
Video output | DVI × 1, CVBS × 1, S-VIDEO × 1, YPbPr × 1, RGBS × 1 |
Other I/O | USB-A (DC 5V 0.5A Output) × 1 |
Power input | DC: 12V, 5A / AC: 100~240V, 50/60Hz |
Typical power | 25 W |
Maximum power | 60 W |
Power saving | < 0.5 W |
Housing color | White |
Dimensions with stand (W × H × D) | 421.8 × 404.2 × 204 mm |
Dimensions without stand (W × H × D) | 421.8 × 344 × 63.7 mm |
Net weight with stand | 6.9 kg |
Net weight without stand | 5.5 kg |
VESA | 100 × 100 mm |
Certifications | CCC |
