S9820

JUSHA S9820 is a 98-inch medical monitor specifically designed for multi-discipline and teaching application. Also, this product fits in the workflow for remote meeting and consulting, providing high quality medical images for reviewing.

Categories: ,
Description

1.DICOM Calibration

Every single unit is DICOM calibrated in factory, meeting the requirements for medical imaging reviewing.



2.48-bit LUT

Each pixel is displayed through 48bit lookup table, presenting a more accurate image and more smooth transition.



3.FocusView

This function applies a mask by tracking the cursor location. This helps users focus on certain area for diagnosis or comparing.



4.Virtual Laser

By changing the cursor into a red point, users can mimic the same feeling of using a laser pen in traditional projectors.



5.Ambient light

With build-in ambient light sensor, the screen will automatically change the brightness with the ambient environment. Also, DICOM standard will be compensated with the ambient light value at the same time, achieving higher medical imaging accuracy.



6.Multi-window

Up to four input signals can be displayed simultaneously, without extra device. This greatly simplifies cable connections and device management.



7.CGA

Color and Grayscale Auto-calibration (CGA) will distinguish color and monochrome pixels automatically, and calibrate the image with corresponding standards, such as DICOM and GAMMA.



8.Eco Mode

When the monitor enters sleep mode, the power consumption is under 0.5W.

Specification
Reviews (0)

Reviews

There are no reviews yet.

Be the first to review “S9820”

Your email address will not be published. Required fields are marked *

Specifications
Model S9820
Type IPS
Retroilluminazione LED
Diagonal size 97.52" (2476.95 mm)
Display area 2158.8 × 1214.4 mm
Resolution 3840 × 2160
Aspect ratio 16:9
Pixel Pitch 0.5622 × 0.5622 mm
Color Depth 30-bit
LUT Depth 48-bit
Viewing angles 178°
Maximum brightness (typical) 500 cd/m²
Maximum calibrated brightness 450 cd/m²
Default brightness 300 cd/m²
Minimum brightness 150 cd/m²
Presets DICOM, GAMMA 2.0, GAMMA 2.2, CIE, DSA
Contrast ratio 1300:1
Response time (Ton+Toff)/2 8 ms
Features Multi-window, Backlight stabilizer, Focusview, Laser pointer, Remote control, USB auto-switching
Video input Single-link DVI × 2, Dual-link DVI × 2, DP 1.2 × 1, HDMI 1.4 × 1, VGA × 1
Video output DP 1.2 × 1, HDMI 1.4 × 1, HDMI × 1
USB Ports Upstream USB-B 2.0 × 6, Downstream USB-A × 1
Power input AC: 100–240 V, 50/60 Hz
Typical power 450 W
Maximum power 600 W
Power saving < 0.5 W
Ambient light sensor Yes
Other sensors Temperature
Protective glass Yes
Housing color Black
Dimensions with stand (W × H × D) 2244 × 2144 × 908 mm
Dimensions without stand (W × H × D) 2244 × 1324 × 127.7 mm
Net weight with stand 309 kg
Net weight without stand 161 kg
VESA 428 × 500 mm
Certifications CCC, CE
